Weldy Brand Geomembrane Welding Machine WGW300

Ask Lasest Price
Brand Name :	Weldy
Model Number :	WGW300
Certification :	CE , ISO
Price :	Negotiable
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	100 SET/week
Delivery Time :	3-5 days after payment

Add to Cart

Product Details
Company Profile

Weldy Brand Geomembrane Welding Machine WGW300

Weldy Brand Original Factory Geomembrane WGW300 Welding Machine

Weldy WGW300 Geomembrane HDPE Pond Liner Welding Machine

Geomembrane Welding Machine Description

The WGW 300 hot-wedge welding machine from Weldy, a Leister brand, welds thermoplastic geomembranes made of HDPE (0.8 to 2.5 mm), LDPE, TPO, FPO, PVC* (0.8 to 3.0 mm), etc. effortlessly and reliably. The geomembranes are typically used in landfills and mines, as well as for aquaculture, fish farms, irrigation systems, etc. and are permanently welded together. The WGW 300 has been deliberately designed to be simple and robust. The electrical controls are intelligently arranged.

Geomembrane Welding Machine Specification

Product Name		Geomembrane Welding Machine
Model		WGW300
Input Voltage		230,50/60HZ
Power		1750W
Wedge Size And Material		80mm CU for HDPE/LDPE. PP
Welding Tracks(others one request)		2x12MM, With Test Channel
Max. Welding Pressure		1400N
Max.Overlap Width		150MM
Motor Speed		0.5-8.5M/Min
Weldable Geomembranes		HPDE 0.8-2.5mm LDPE/TPO/FPO/PVC 0.8-3.0MM ,Geomtexile ) (PVC With Steel Wedge Only
Max .Wedge Tem.		450℃
Country of Origin		Made in China
Net Weight		15KG

Geomembrane Welding Machine Features

A: Heating and motor can be turned on and off directly with the controls, which enables fast, safe and intuitive operation;
B: WGW 300 weighs 15 kg and can be easily stored and transported in the storage box supplied;
C: A steel wedge is required for welding PVC geomembranes;
D: The WGW 300 automatic welder is equipped with a powerful and durable motor;

Geomembrane Weldng Machine Customer operation

All designed according to ISO21307:2011(E),ISO12176-1 and DVS2207/1(08/2007)
International warranty: 24months.
Any parts broken or does not work under normal operating,we are free to provide.
