ZEMO 5.35KW HDPE Butt Fusion Welding Machine , IPS HDPE Pipe Joint Machine

Ask Lasest Price
Brand Name :	ZEMO
Model Number :	SMD-B315/90H (3-12")
Certification :	CE , ISO
Price :	Negotiation
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	300 set/month
Delivery Time :	3-7 working days after payment

Add to Cart

Product Details
Company Profile

ZEMO 5.35KW HDPE Butt Fusion Welding Machine , IPS HDPE Pipe Joint Machine

220V IPS HDPE Pipe Joint Machine

HDPE Pipe Joint Machine Description

Hot-melt butt welding machine is a special welding equipment that applies hot-melt butt technology to weld thermoplastic pipes and fittings. The welding frame of the hot melt butt welder is separate from the operating system. The whole machine (automatic type, hydraulic semi-automatic type) consists of hydraulic operation console, welding frame and fixture, electric heating plate, electric milling cutter and other parts. The manual type has no hydraulic system. The welding frame is made of high-strength aluminum alloy material, with a firm structure, light and durable. The welding frame adopts the compression structure of the mica sheet of the card sleeve, the positioning of the pipe is accurate, and the amount of misalignment is easy to adjust.

HDPE Pipe Joint Machine Features:

Removable PTFE coated heating plate with separate temperature control system.

Electrical planning tool;

Be made of lightweight and high strength material; simple structure, small and delicate user friendly;

Low starting pressure ensures reliable welding quality of small pipes;

Separate two-channel timer shows time in soaking and cooling phases;

High-accurate and shockproof pressure meter in indicates clear readings.

HDPE Pipe Joint Machine  Specification

Product Name		HDPE Pipe Joint Machine
Model		SMD-B315/90H (3-12")
Pipe size (Inch)		3-12 Inch
Application		PE Pipe & Fitting Welding
Heating plate Max. Temperature		270℃
Temp.deviation in surface (170-250 ℃)		≤±7℃
Pressures Adjustable Ranges		0-6.3Mpa
Working Voltage		220V /110, 50/60HZ , single phase
Heating plate power		3.5KW
Planing tool power		1.1KW
Hydraulic unit power		0.75KW
Total Power		5.35KW
Weight		216KG
Packing	Cases	3 plywood cases
	Volume	0.99CBM

Zemo Welding Machinrey Co.,LTD (ZEMOWELD) is one of comprehensive manufacturer of Thermoplastic Welding Equipment and an experienced professional exporters in China ZEMO products included Butt Fusion Machine,Socket Fusion Machine, Electrofusion Machine,Hot Air Welders,Hot Air Welding Machine, Extrusion Welders, Geomembrane Overlap Wedge Welders,Band Saw,Workshop Fittings Machine,and Welding Accessories Required under the ISO9001 system and approved to CE standards by SGS.
Plastic Welding Machine's One Stop sourcing Platform,ZEMO will serve world thermoplastic material industry.

All designed according to ISO21307:2011(E),ISO12176-1 and DVS2207/1(08/2007)
International warranty: 24months.
Any parts broken or does not work under normal operating,we are free to provide.
